Forecast the usage of a GitLab namespace

In this lab we will use the forecast command to forecast potential GitHub Actions usage by computing metrics from the historical pipeline data in our GitLab instance. The metrics will be stored on disk in a markdown file and include job metrics for execution time, queue time, and concurrency. We will look at each of these metrics in more depth later in this lab.

Prerequisites
Prepare for forecast
Perform a forecast
Review forecast report
Review additional files
Forecasting multiple providers
Next steps

Prerequisites

Followed steps to set up your codespace environment.
Completed the configure lab.
Ran the setup script in the terminal to make sure the GitLab instance is ready.
```
source gitlab/bootstrap/setup.sh
```

Prepare for forecast

Before we can run the forecast we need to answer a few questions so we can construct the correct command.

What namespace do we want to run the forecast for? valet. This is the only group in the demo GitLab instance.
What is the date we want to start forecasting from? 2022-08-02. This date is before the time the data was populated on our demo GitLab instance. In practice, this should be a date that will give you enough data to get a good understanding of the typical usage. Too little data and the metrics might not give an accurate picture
Where do we want to store the results? ./tmp/forecast_reports. This can be any valid path on the system, but for simplicity it is recommend to use a directory in the root of the codespace workspace.

Perform a forecast

Using the answers above we get the following forecast command:

gh valet forecast gitlab --output-dir ./tmp/forecast_reports --namespace valet --start-date 2022-08-02

Run the command in the codespace terminal.
Verify that the command output is similar to this.

Review forecast report

Open the forecast report and review the calculated metrics.

From the codespace explorer pane find ./tmp/forecast_reports/forecast_report.md and right-click, and select Open Preview.
The file should be similar to this.
example forecast_report.md

Forecast report for GitLab
- Valet version: 0.1.0.13432(03b5bc9370a8f0073c0cc1a4b25f6b81d0005c0f)
- Performed at: 8/17/22 at 20:00
- Date range: 2/8/22 - 8/17/22
Total
- Job count: 57
- Pipeline count: 15
- Execution time
  - Total: 135 minutes
  - Median: 0 minutes
  - P90: 7 minutes
  - Min: 0 minutes
  - Max: 10 minutes
- Queue time
  - Median: 0 minutes
  - P90: 5 minutes
  - Min: 0 minutes
  - Max: 42 minutes
- Concurrent jobs
  - Median: 0
  - P90: 0
  - Min: 0
  - Max: 9
gitlab-runner
- Job count: 57
- Pipeline count: 15
- Execution time
  - Total: 135 minutes
  - Median: 0 minutes
  - P90: 7 minutes
  - Min: 0 minutes
  - Max: 10 minutes
- Queue time
  - Median: 0 minutes
  - P90: 5 minutes
  - Min: 0 minutes
  - Max: 42 minutes
- Concurrent jobs
  - Median: 0
  - P90: 0
  - Min: 0
  - Max: 9
Note: Concurrent jobs are calculated by using a sliding window of 1m 0s.

Metric Definitions

Name	Description
Median	The middle value
P90	90% of the values are less than or equal to
Min	The lowest value
Max	The highest value

Total Section

This section shows the metrics for all of the jobs run in projects contained in the valet namespace, from 08/02/2022 to the time the command was executed.

Total
- Job count: 57
- Pipeline count: 15
We can see we ran 15 pipelines that contained 57 jobs. The number of jobs is expected to be larger than pipelines because a pipeline is typically a collection of jobs. For example basic-pipeline-example contains 6 jobs
Execution time shows the metrics for the time a job took to run. Looking closer we can see during our forecast timeframe the total job run time was 135 minutes with 90% of the jobs finishing under 7 minutes, and the longest job taking 10 minutes. The min is 0 because the quickest job took less than a minute and was rounded down to 0.
- Execution time
  - Total: 135 minutes
  - Median: 0 minutes
  - P90: 7 minutes
  - Min: 0 minutes
  - Max: 10 minutes
Queue time shows the metrics for how long jobs waited for a runner to be available.
- Queue time
  - Median: 0 minutes
  - P90: 5 minutes
  - Min: 0 minutes
  - Max: 42 minutes
Concurrent jobs show the metrics for how many jobs were run at the same time.
- Concurrent jobs
  - Median: 0
  - P90: 0
  - Min: 0
  - Max: 9

Runner Group Sections

The preceding section shows the same metrics as the Total section, but are grouped by runner group. A runner group is a machine (or group of machines) that each job runs on
In this case we only have one runner group gitlab-runner so the metrics match the Total section. If there were different groups we could possibly identify runner types that needed to be increased or decreased when moving to GitHub Actions

gitlab-runner
- Job count: 57
- Pipeline count: 15
- Execution time
  - Total: 135 minutes
  - Median: 0 minutes
  - P90: 7 minutes
  - Min: 0 minutes
  - Max: 10 minutes
- Queue time
  - Median: 0 minutes
  - P90: 5 minutes
  - Min: 0 minutes
  - Max: 42 minutes
- Concurrent jobs
  - Median: 0
  - P90: 0
  - Min: 0
  - Max: 9

Forecasting multiple providers

If we examine the help for the forecast command by running gh valet forecast --help we can see a new option --source-file-path

Using --source-file-path we can combine data from multiple forecast runs into a single report. This becomes useful if we are using multiple CI/CD providers, such as GitLab and Jenkins, and wanted to get a holistic view of the runner usage across the providers. The way this works is the forecast command creates a .json file in a jobs directory for each command execution. The --source-file-path takes a space-delimited list of data file paths or a glob pattern that will match all of the data files we want to include and combine into a single report. We will use a glob pattern, which in general should match OUTPUT_DIR/**/jobs/*.json where the OUTPUT_DIR is the previous value used for --output-dir, which in this lab was ./tmp/forecast_reports. We do not have multiple providers but we can still try it out because we have a data file at tmp/forecast_reports/jobs/!

run gh valet forecast --source-file-path tmp/**/jobs/*.json -o tmp/combined-forecast
Now we have a new report that was generated from all the data files that matched the glob pattern. Note this command does not introspect the CI/CD provider, it only operates on the data files it finds.

Next steps
